Bio-Plex Manager Software 6.1 User Guide | Starting Bio-Plex Manager
16
Connecting with the Array Reader and
Microplate Platform
The computer running Bio-Plex Manager software is connected to the array
reader by a USB cable, and to the microplate platform by a serial cable. See
the figure below for a diagram of the cable connections.
Figure 5. System cable connections
Microplate Platform
Power
Serial port
Array Reader
Power
P1
P2
HTF
Computer
Serial
port
Power
Serial port
Power
USB1
USB2
