P O S 4 0 0 0
Document Number:
POS4007
27
Document Title:
POS4000/V2 WSII Operations Manual
For example, if you have a console with 4 programs, 4 options and 4 groups and you don't use
group 4 and the carwash doesn't have program 4 or options 3 and 4, you disable the unused
keys as follows:
[CMD]
[SYSTEM SETUP]
[3]
(password
3)
[ENTER]
[MENU UP/DOWN] until "Disable Cashier Key" is displayed
[ENTER]
[Prog 4]
(disable program 4)
[Opt
3]
(disable
option
3)
[Opt 4]
(disable option 4)
[Group 4]
(disable group 4)
[ENTER]
Example to re-enable all cashier keys:
[CMD]
[SYSTEM SETUP]
[3]
(password
3)
[ENTER]
[MENU UP/DOWN] until "Disable Cashier Key" is displayed
[ENTER]
[ENTER]
(no cashier keys pressed)
Note:
Cashier keys that have been disabled MUST be re-enabled using the above steps.
Note:
All programs and options not available on your particular carwash and all group
packages not programmed and used by you must be disabled if the buy up option is
enabled.
4.1.6 Set Serial Baud Rate
This command allows you to change the serial baud rate of the cash register port on the console.
This rate only needs to be changed if you are connecting to an External Point of sale device.
To select this command scroll through the configuration secondary menu until "Set Serial Baud"
is displayed and then press the [ENTER] key. You will then be prompted to enter the new baud
rate. Only standard baud rates are allowed: 1200, and 2400, 4800,9600, and 19200. If you enter
one of these rates, it will be saved. If you enter any other rate, an error message is displayed and
the baud rate is not changed.
Example for setting the baud rate to 9600:
[CMD]
[SYSTEM SETUP]
[MENU UP/DOWN] until "Set Baud Rate" appears
[ENTER]
[9][6][0][0]
[ENTER]
