P O S 4 0 0 0

Document Number:

POS4007

79

7.1.2 Setting and Removing the Printer Cover

The figure below illustrates setting and removing the printer cover.



Figure 5. Setting and Removing the Printer Cover

7.1.3 Ribbon and Cassette Installation

In order to set the ribbon, disconnect the power source before hand. When the printing has been
continued for many hours, be careful not to touch the printer head, as it might be hot.

1. Remove the printer cover.

2. While inserting the ribbon into the space between the print head and the ribbon guide,

press the cassette into the holder until, it clicks into place. (Refer to fig. 4 & 5)

3. Turn the cassette ribbon knob in the direction of the arrow to take up slack in the ribbon.

Document Title:

POS4000/V2 WSII Operations Manual
