Table 4. Connections to Customer Entry system
Connector
Direction
Entry system Connection
A-7
>
Power for customer lights
A-6 <
"Out-of-Service"
light
A-5
<
"Enter Wash" light (Code valid)
A-4
<
"Code Accepted / Wait" light
A-3
<
"Reenter Code" light (code invalid)
D-3
>
Quarter mechanism voltage pulse (credit)
D-4
>
Quarter mechanism voltage neutral
D-5
>
Bill mechanism voltage pulse (credit)
D-6 >
Bill
mechanism voltage neutral
Table 5. Power and Audit Connections
Interface
Connector
Direction
Power/Audit Connection
A-1
>
24VAC HOT power to interface board (or 24VDC+)
A-2
>
24VAC neutral (or 24VDC-)
D-7
>
Audit 1 Voltage Input
D-b
>
Neutral for ALL audit voltage inputs
D-9
>
Audit 2 Voltage Input
D-10
>
Audit 3 Voltage Input
D-11
>
Audit 4 Voltage Input
D-12
>
Audit 5 Voltage Input
