P O S 4 0 0 0
Document Number: POS4007 82
Document Title: POS4000/V2 WSII Operations Manual
7.1.7 DIP Switch Settings
The following table lists the DIP Switch settings for Citizens Printers Models 3530 and 3535.
Table 16. Printer DIP Switch Settings
DIP
Switch
ON OFF
1 X
2 X
3 X
4 X
5 X
6 X
7 X
8 X
7.2 Instructions for Citizen Model CD-S500
Refer to the Citizen CD-S500 operations manual, page 36 for more information on configuring
the printer.
Table 17. Citizen CDS500 Printer Settings
Configuration Settings
Command Type CBM2
Number of Col. 42/35
Font Select 7*9
To configure the printer for operation with the POS4000, perform the following procedure:
1. With the front cover open, turn power on while pressing the FEED button; then release
the FEED button.
2. The POWER LED will flash as the printer enters the maintenance mode; close the front
cover.
3. Press the FEED button until you hear a single beep; reopen and close the front cover.
4. Press the FEED button until you hear a single beep and release it. The printer will print
the setting for COMMAND TYPE. Continue to press the FEED button until the printer
prints “Command Type -CBM2”.
5. Press and hold the FEED button until you hear a single beep followed by three quick
beeps.
