2.2.1 Wiring Information for POS4000 Interface Board

The following tables list the wiring information for the POS4000 Interface Board.

Note:

>

is a signal input to interface board

<

is a signal output from interface board

Table 2. Connector-Pin Communications Link to POS4000 Console

Interface

Connector

Direction

Pin

C-1

<>

Pin 1 (RS485 -)

C-2

<>

Pin 2 (RS485 +)

C-3

<>

Pin 3 (Signal GND)

(not connected)

C-4

<>

Earth Ground (connected to
Earth manually or via Hard

wired Earth ground cable

Note:

On POS4000 Interface boards with Version 6.6 Hardware the Pin C-4 is connected
internally to Signal Ground.

Table 3. Connections to Carwash Controller

Connector

Direction

Controller Connection

D-1

>

Car Wash “IN USE” Signal

D-1

>

Car Wash “IN-USE” Neutral

A1-8

>

Car Wash Voltage to activate wash functions

B-1 <

Function

1*

B-2 <

Function

2*

B-3 <

Function

3*

B-4 <

Function

4*

B-5 <

Function

5*

B-6 <

Function

6*

B-7 <

Function

7*

B-8 <

Function

8*

*See Section 2.3 for "Function" descriptions
