4 Operation
790 Personal IC
78
4.3.6 Instrument icon
Menu options for instrument icon
System
disconnected
System connected
Injection valve in
" INJECT" position
System connected
Injection valve in
" FILL" position
The instrument icon for the 790 Personal IC is one of the components
of the SYSTEM window. If the system is connected, the 790 icon con-
tains two buttons for manual control of the injection valve:
Switch injection valve to "INJECT" position.
Switch injection valve to "FILL" position.
If the system is connected and the 790 icon is clicked with the right
mouse button, the following menu appears:
Open Open the system settings window.
Hardware Open the hardware settings window.
Diagnostics Open the diagnostics window.
System parameters for disconnected system
A double-click on the instrument icon or selection of the Open menu
item using the right mouse button opens the system settings window.
For a disconnected system, the Initial tab is displayed.
Flow, mL/min Startup value for flow rate of the high-pressure
pump.
Entry range: 0.20 ... 2.50 mL/min
