2 Installation

790 Personal IC

• Insert the cable permanently attached to the detector block

38 in one of the openings 5555 and the outlet capillary in one of

the openings 7

777 of the rear panel 9999.

• Replace rear panel 9999 and screw to the 790 Personal IC using

the four knurled screws 8

888.

3 Connect detector block

• Plug the gray connecting cable permanently attached to the

detector block 38

38 into connection 15

15 "Detector Block" of the

790 Personal IC and fasten to the instrument by tightening

the screws in the cable connector (see Fig. 2).

4 Connect waste container

• Lead the outlet capillary of the detector block 38

38 to a suffi-

ciently large waste container and fix in place.

2.3.2

Connection of syringe and aspirating tubing

For manual filling of the sample loop 22

22 mounted on the injection valve,

the 6.2816.020 Syringe, the syringe tubing 25

25 with coupling 24

24 and the

PTFE aspirating tubing 23

23 are needed. These accessories are mounted

as follows:

1 Connect syringe to syringe tubing

• Pull syringe tubing 25

25 connected to injection valve 22

22 by

hand out of feedthrough 3

333 as far as desired (see Fig. 3 and

Fig. 4).

• Mount a PEEK compression fitting 46

46 (see section 2.3.4) to

the end of the syringe tubing 25

25 and screw the coupling 24

(6.2744.120) to the compression fitting 46

46.

• Push 6.2816.020 Syringe (without needle) as far as it will go

into the connection of coupling 24

24.

2 Install aspirating tubing

• Pull aspirating tubing 23

23 connected to injection valve 22

22 by

hand out of feedthrough 4

444 as far as desired (see Fig. 3 and

Fig. 4).

2.3.3

Connection of the 6.5324.000 Bottle rack (option)

The optional available 6.5324.000 Bottle rack for supply vessels can be

placed on top of the 790 Personal IC. The accessories include the sup-

ply vessels for eluent (2 L), regeneration solution (1 L) and rinsing solu-

tion (1 L).
