60
Outputs: - analog 0 to 5V or -2.5 to +2.5V, output current: max 10 mA. Voltage error:
+/- 4 % max. 0 position: +/- 100 mV.
- absolute analog 6 to 10 V with a P10, 0 to 10 V with a P25/P50
- optocoupled output signals for sort and for pneumatic unit D110 command.
- Centronics port for link with printer.
- RS-232-C port for linking to computer or printer.
- command for optional multichannel unit D102/D104/D108
Inputs: - 2 external contacts, e.g. supplied foot pedal
- RS-232-C port for remote command from a computer
Charger: - country specific, supplied in one of the following 4 types:
- European standard plug 230V +/- 10 % 50-60 Hz
- US standard plug 120V +/- 10 % 50-60 Hz or for Japan: 100 V +/- 10 %
50-60 Hz
- UK standard plug 240V +/- 10 % 50-60 Hz
For all 4 models: output 8.5 V/700 mA
Data back-up: Lithium module 3 V 175 mAh Renata type 175-OB. Lifetime approx. 10 years.
Autonomy: approx. 8 hrs NB. Autonomy is reduced at higher working temperatures. At
40°autonomy is reduced by 70 % compared to 25°C.
Charge: 15 hrs. minimum. The charger can be connected permanently without dama-
ging the accumulators.
Self discharge of accumulators: loss of 30% of accumulator capacity per month. Do not leave accumulators
completely uncharged.
Lifetime of accumulators: approx. 4-5 years.
1.13 DELIVERY
Packaging in synthetic material Order No
- D100S unit (with accumulator) 804.1101
- 1 charger European 230 V 904.4010
UK 240 V 904.4011
US 120 V 904.4012
Japanese 100 V 904.4013
- 1 foot pedal for external contact 904.4101
- 1 base (to increase incline)
- 1 instruction manual
