Bowers Group Groove measurement User Manual
Special applica tions, Bowers metrology, Subject : groove measurement

Bowers Metrology Ltd, 32 Leeds Old Road, Bradford, England, BD3 8HU
Tel :(0044) 01274 223456 Fax :(0044) 01274 223444
Email : [email protected]
BOWERS METROLOGY
SPECIAL
APPLICA
TIONS
Subject : Groove Measurement
The following features can be
inspected using Bowers groove heads :
• Plain grooves
• Oil seal grooves
• “O” ring grooves
• Ball races
• Annular grooves
• Special forms
•
2 or 3 anvil contact
• Depth stops available if required
• Diameters 2 - 300 mm
• Grooves are very widespread in most areas of manufacturing. Particularly so in vehicle
and aircraft production.
• Bore entry diameter
• Groove diameter
• Groove width
• Measurement depth
• Bowers digital system required (XT-Holematic / XTD / Superbore)
If an order is received, please provide a drawing of the part to enable us to ensure that all
details are correct before proceeding to manufacture.
Details
Head features
Range available
Customer profile
Information required
3-point
2-point
Oil seal
O rings
Ball race
Annular
Special forms
