1.6.10 PRESET KEY
Displays stored preset value.
The external contact (e.g. foot pedal) can also be configured to preset the displayed value.
Any preset value may be input, also 0.000 for zeroing the display.
Each channel (from 1 to 64) has its own preset value.
Input of a preset value:
1/ press 2/ then Following will be displayed:
3/ the old preset value is displayed. Enter preset value according to general
principle described in Section 1.3.3. To enter a preset of 0.000, simply
press 0 then .
The key automatically introduces the stored preset value for the num-
ber of channels defined for scanning mode.
4/ if the current channel number is smaller than scanning number, the following will be displayed:
- exit preset input mode.
- input preset value for the next channel.
To calibrate the input unit with a master, the different presets are introduced with
the master and probes in the measuring position.
A new calibration can be made as follows:
In normal mode: press then then .
In scanning mode: simply press .
Once the preset value has been entered, the unit reverts to measuring mode and displays the preset value. Had more
preset values been entered, each channel would be affected by its respective value.
If one channel is in A+/-B or A+/-B+/-C mode, the measurement preset is stored on channel A, the value of the channel
B preset remaining unchanged.
After a general reset ( + ), the preset values of all channels will be reset to zero.
Next channel ?
No –> CLEAR
Yes –> ENTER
CHANNEL 1
Enter preset value :
0.000 IN
Scan = Auto
