44
- KEY0
= keyboard locked.
- KEY1
= keyboard unlocked.
- RST
= general reset of the unit (return to initial status).
- SET?
= the unit transmits general parameters:
MM
RES 1
ANA 0
TOL 0
CLA 0
STO 0
KEY 0
or
IN
2
1
1
1
1
1
Note: STO0/1 indicates if hold function is active or not.
- MEM?
= requests memory configuration of unit. All 5000 parameters are transmitted in one
block, without Xon/Xoff protocol, at 9600 bps, 8 bits, no parity.
- MEMR
= restores memory configuration of unit, same transmission parameters as above.
- DIS BLA...BLA...
= displays a 20 characters max message on the first line of the D100S display. The
end of message is given by CR (Carriage Return). This message is cleared by pressing
any key on D100S unit or by sending DIS only followed by CR.
- EXT 0
= allocates data transmission function to external contact (foot pedal). Refer to Section
1.6.11.
- EXT 1
= display hold or store.
- EXT 2
= reset Min/Max registers.
- EXT 3
= preset display.
- EXT 4
= change of channels.
- EXT 5
= D110 command.
- EXT 6
= start scanning.
- EXT 7
= status transmitted automatically.
- EXT 8
= status transmitted on request.
- EXT 9
= transmission of values + display hold or store.
- EXT 10
= new Min/Max then transmission of values.
- EXT 11
= preset then transmission of values.
- EXT 12
= transmission of values + change channels.
- EXT 13
= D110 command then transmission of values.
- EXT 14
= start scanning then transmission of values.
- EXT 15
= D110 command then start scanning and transmission of values.
- EXT 16
= D110 command then start scanning.
- EXT 17
= new Min/Max then store or hold.
- EXT 18
= preset then store or hold.
- EXT 19
= store + change channels.
- EXT 20
= D110 command then store or hold.
- EXT 21
= start scanning then store.
- EXT 22
= D110 command then start scanning then store.
- EXT 23
= store/hold + print + scanning.
- EXT 24
= new Min/Max (if necessary) then store/hold and change channel.
- EXT 25
= new Min/Max then print + change channel.
- EXT 26
= new Min/Max then change channel.
- EXT 27
= print + store + change channel.
- EXT 28
= D110 command then print and store.
- EXT 29
= preset then scanning.
- EXT ?
= request status of external contact (corresponding to EXT 8):
- the unit transmits 0 (zero) if no external contact.
- the unit transmits 1 if an external contact has occurred (status is automatically reset
to 0).
