c/ printing example of statistical analysis and stored values (tolerances activated):
SYLVAC SA
Piece ident. : SHAFT
Drawing nbr : PM230.010.412
Work station : L 201
Date : 12/11/1998 Time : 14:46
CHANNEL 1+ 2
N 30
Xmax 8.361 Xmin 8.338
R 0.023 Xbar 8.352
Sigma 0.0063 s 0.0064
-3 S 8.333 +3 S 8.371
- NG 1 + NG 0
%Def 3.333 Cp 0.7933
Cpk 0.6433 Cm 0.7800
Cmk 0.6325
0 + NG
ULT -------------------- 8.3700
0
8.3640
################ 7
8.3580
##################### 9
8.3520
##################### 9
8.3460
######### 4
LLT -------------------- 8.3400
*** 1 - NG
1 8.342 2 8.342
3 8.350 4 8.359
5 8.359 6 8.358
7 8.342 8 8.344
9 8.354 10 8.348
11 8.356 12 8.360
13 8.360 14 8.357
15 8.353 16 8.351
17 8.348 18 8.350
19 8.353 20 8.349
21 8.349 22 8.349
23 8.350 24 8.354
25 8.353 26 8.338
27 8.361 28 8.361
29 8.361 30 8.354
