2.2/ Peripheral choice, the following menu will appear:
These different choices modify the output format for the Centronics/RS232 out-
puts.
Remote command of the unit will not be modified.
80 and 40 column formats allow the header to be printed following the user's
parameters.
2.2.1/ Connection to a computer. This is the most simple transmission format allowing easy processing of values.
The measurement is transmitted as it appears on the display:
a/ In mm:
SIGN 102 101 100 DP 10-1 10-2 10-3 10-4 CR LF
or 103
= space if positive sign DP = decimal point LF only if requested
102 et 101 =space if zero 10-4, 10-3 and 10-2 only with resp.
resolutions 0.1 µm, 1 µm and 10 µm.
The sign always immediately precedes the 1st digit.
b/ In inch:
SIGN 101 100 DP 10-1 10-2 10-3 10-4 10-5 CR LF
101 = space if zero 10-5, 10-4 and 10-3 only with resp.
resolutions 0.00001, 0.0001 and 0.001 in
c/ In scanning mode the values are transmitted as follows:
5. < = number of measured workpiece followed by < (reject), = (good) or > (rework) if TOL active.
10.002 = measured value of channel 1
20.002
12.003
7.999 to channel n.
+ CR (+ LF) extra to indicate end of transmission of measurements.
d/ Stored values are transmitted from first to last. Between each measurement, a CR (+ LF) is transmitted.
e/ Statistical values are transmitted as follows:
CHANNEL 1 = Channel No. for which statistics are transmitted
N 28 the statistical values are transmitted in the same order as they appear on the screen
Xmax 10.004 (refer to Section 1.6.9). The histogram is not transmitted
Xmin 9.998
R 0.006
Xbar
10.000
Sigma 0.0017
s 0.0017
-3S 9.995 This value and the following are only transmitted if tolerances are activated
+3S 10.005
Enter the choice:
1 : Computer
2 : 80 col. Printer
3 : 40 " "
4 : 15 " "
