Digital Inputs
78 Rockwell Automation Publication PFLEX-RM001H-EN-P - June 2013
The table below describes the various reference sources that can be selected
using all three of the Speed Select input functions.
If any of the three Reference Select input functions are not configured, then
the software will still follow the table, but will treat the unconfigured inputs as
if they are permanently open.
As an example, the table below describes what reference selections can be
made if “Speed Select 1” is the only configured input function. This
configuration allows a single input to choose between [Speed Ref A Sel] and
[Speed Ref B Sel].
As another example, describes what reference selections can be made if the
“Speed Select 3” and “Speed Select 2” input functions are configured, but
“Speed Select 1” is not.
Speed Select 3 Speed Select 2 Speed Select 1 Parameter that determines Reference
Open Open Open [Speed Ref A Sel]
Open Open Closed [Speed Ref B Sel]
Open Closed Open [Preset Speed 2]
Open Closed Closed [Preset Speed 3]
Closed Open Open [Preset Speed 4]
Closed Open Closed [Preset Speed 5]
Closed Closed Open [Preset Speed 6]
Closed Closed Closed [Preset Speed 7]
Speed Select 1 Selected Parameter that determines Reference
Open [Speed Ref A Sel]
Closed [Speed Ref B Sel]
Speed Select 3 Speed Select 2 Selected Parameter that determines reference
Open Open [Speed Ref A Sel]
Open Closed [Preset Speed 2]
Closed Open [Preset Speed 4]
Closed Closed [Preset Speed 6]
