SU/CD Trend Parameters
The XM-122 module can collect startup or coast-down trend data when the
machine speed passes into a defined speed range. A tachometer input is
required to collect the startup/coast-down trend.
The XM-122 collects a startup trend when the machine speed rises through
the Minimum Speed + 8 RPM, and stops when the machine speed crosses
either the Minimum Speed or the Maximum Speed. The module collects
data only when machine speed is increasing. It does not collect data if the
machine speed is constant or decreasing.
Trend Span
The total amount of time that can be covered by the
trend data (Number of Records x Record
Interval).
Note: If you edit the Trend Span, the Record
Interval is automatically updated.
Seconds
Post Trigger
The percentage of records to be collected once the
trigger occurs. For example, if you set Post Trigger to
20%, then 80% of the records in the trend are before
the trigger occurs, and 20% of the records in the
trend are after the trigger occurs.
This allows you to evaluate what happened after the
trigger occurred.
0 to 100 Percent
Status
Shows the status of the trend data.
Possible status values:
•
Not collected - No trend data is
currently collected.
•
Collecting - A trigger has occurred
and data (including post-trigger
data) is being collected.
•
Collected - A trend has been saved
to the buffer and is available to view
and upload.
Store Spectrum
Stores the current spectrum data for both Channel 1
and Channel 2 when the trigger occurs.
Store Waveform
Stores the current waveform data for both Channel 1
and Channel 2 when the trigger occurs.
View Trend Data
Displays a plot of the collected trend data.
Reset Trigger
Resets the trigger if Latch enabled is selected. This
allows the module to overwrite the previous trend
data when the next trigger occurs.
Manual Trigger
Triggers the module to collect the trend data without
relay activation.
View Collected Data
Displays a plot of the collected spectrum or
waveform data.
Triggered Trend Parameters
Parameter Name
Description
Values/Comments
