Publication GMSI10-UM013D-EN-P - May 2010
DeviceNet Objects 173
Transducer Object
(Class ID 328
H
)
The Transducer Object models a transducer.
Class Attributes
The Transducer Object provides no class attributes.
Instances
There are 3 instances of this object. Transducer Object instance 1 is for
vibration channel 1. Transducer Object instance 2 is for vibration channel 2,
and Transducer Object instance 3 is for the tachometer channel.
Instance Attributes
Table C.62 Transducer Object Instance Attributes
Attr ID
Access
Rule
Name Data Type Description Semantics
3 Get DC Bias REAL The measured average DC
bias of the transducer
signal in volts. Volts
4 Get Status BOOL Indicates whether a
transducer fault exists
(the measured DC Bias is
outside the range
specified by Fault High
and Low). 0 = No fault
1 = A transducer fault exists
5 Get/Set Sensitivity
Value REAL Value of the sensitivity of
the transducer in
millivolts per Sensitivity
Units.
6 Get/Set Sensitivity Units ENGUNIT Units of the denominator
of the Sensitivity Value. See DeviceNet Specification
Volume 1 Appendix K. Also see
Parameter Object instances 1
and 2.
Valid values:
g =1504 hex
in/sec = 2B07 hex
mils = 0800 hex
psi = 1300 hex
volt = 2D00 hex
mm/s = 0900 hex
µm = 2204 hex
Pa = 1309 hex
