Introduction 3
•
XM-122 gSE Vibration Module - The module mounts on the XM-940
terminal base via a keyswitch and a 96-pin connector. The module
contains the measurement electronics, processors, relay, and serial
interface port for local configuration.
Using this Manual
This manual introduces you to the XM-122 gSE Vibration module. It is
intended for anyone who installs, configures, or uses the XM-122 gSE
Vibration module.
Organization
To help you navigate through this manual, it is organized in chapters based on
these tasks and topics.
Chapter 1 "Introduction" contains an overview of this manual and the
XM-122 module.
Chapter 2 "Installing the XM-122 gSE Vibration Module' describes how to
install, wire, and use the XM-122 module.
Chapter 3 "Configuration Parameters" provides a complete listing and
description of the XM-122 parameters. The parameters can be viewed and
edited using the XM Serial Configuration Utility software and a personal
computer.
Appendix A "Specifications" lists the technical specifications for the XM-122
module.
Appendix B "DeviceNet Information" provides information to help you
configure the XM-122 over a DeviceNet network.
Appendix C "DeviceNet Objects" provides information on the DeviceNet
objects supported by the XM-122 module.
IMPORTANT
The XM-441 Expansion Relay module may be connected
to the XM-122 module via the XM-940 terminal base.
When connected to the module, the Expansion Relay
module simply “expands” the capability of the XM-122 by
adding four additional epoxy-sealed relays. The XM-122
controls the Expansion Relay module by extending to it the
same logic and functional controls as the on-board relay.
