Publication GMSI10-UM013D-EN-P - May 2010
130 DeviceNet Objects
Instance 106 - Measurement Values
This Assembly instance can be selected to be sent in response to an I/O Poll
request from a Master. This instance includes some Vector Magnitude
measurements first.
40 - 43
Channel 1 Band 1 value
44 - 47
Channel 2 Band 1 value
48 - 51
Channel 1 band 2 value
52 - 55
Channel 2 Band 2 value
56 - 59
Channel 1 Band 3 value
60 - 63
Channel 2 Band 3 value
64 - 67
Channel 1 Band 4 value
68 - 71
Channel 2 Band
72 - 75
Channel 1 Vector 3 Magnitude value
76 - 79
Channel 2 Vector 3 Magnitude value
80 - 83
Channel 1 Vector 1 Phase value
84 - 87
Channel 2 Vector 1 Phase value
88 - 91
Channel 1 Not 1X value (AIP Object Instance #3)
92 - 95
Channel 2 Not 1X value (AIP Object Instance #4)
96 - 99
Channel 1 Sum Harmonics value (AIP Object Instance #7)
100 - 103
Channel 2 Sum Harmonics value (AIP Object Instance #8)
104 - 107
Channel 1 Vector 2 Phase value
108 - 111
Channel 2 Vector 2 Phase value
112 - 115
Maximum Speed value
116 - 119
Channel 1 Gap value (AIP Object Instance #1)
120 - 123
Channel 2 Gap value (AIP Object Instance #2)
Table C.15 Instance 105 Data Format (Measurement Values Assembly)
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Table C.16 Instance 103 Data Format (Measurement Values Assembly)
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0 - 3
Channel 1 Vector 1 Magnitude value
4 - 7
Channel 2 Vector 1 Magnitude value
8 - 11
Channel 1 Vector 2 Magnitude value
12 - 15
Channel 2 Vector 2 Magnitude value
16 - 19
Speed value
20 - 23
Channel 1 Overall value
24 - 27
Channel 2 Overall value
