Page 14

Publication GMSI10-UM013D-EN-P - May 2010
4 Introduction
Appendix D "Wiring Connections for Previous Module Revisions" provides
the terminal block assignments and wiring diagrams of earlier revisions of the
XM-122 module (before revision D01).
Appendix E "Guidelines for Setting the Full Scale Value" provides guidelines
for determining the optimal Channel Transducer Full Scale value in the
XM-122 module.
For definitions of terms used in this Guide, see the Glossary at the end of the
Guide.
Document Conventions
There are several document conventions used in this manual, including the
following:
The XM-122 gSE Vibration module is referred to as XM-122, device, or
module throughout this manual.
TIP
A tip indicates additional information which may be
helpful.
EXAMPLE
This convention presents an example.
