Publication GMSI10-UM013D-EN-P - May 2010
DeviceNet Objects 133
The dynamic Assembly instance must be instantiated with a call to the class
level Create service. Then the structure can be defined with the
Set_Attribute_Single service for the Member List attribute. Only one dynamic
Attribute instance is supported so subsequent calls to the Create service will
return a Resource Unavailable (0x02) error. The Delete service can be used to
destroy the dynamic Assembly instance so that it can be re-created.
Services
Connection Object
(Class ID 05
H
)
The Connection Object allocates and manages the internal resources
associated with both I/O and Explicit Messaging Connections.
Class Attributes
The Connection Object provides no class attributes.
Instances
Table C.18 Assembly Object Services
Service
Code
Class/Instance Usage Name
0E
h
Class/Instance Get_Attribute_Single
10
h
Instance Set_Attribute_Single
08
h
Class Create
09
h
Instance Delete
Table C.19 Connection Object Instances
Instance Description
1 Explicit Message Connection for pre-defined connection set
2 I/O Poll Connection
3 I/O Strobe Connection
4 I/O COS (change of state) Connection
11 - 17 Explicit Message Connection
