Publication GMSI10-UM013D-EN-P - May 2010
108 DeviceNet Information
The Poll response data can also be requested explicitly through Assembly
Object (Class ID 0x4), Instance 101 (0x65) - 106 (0x6A), Data Attribute (3).
The following tables show the static data format of Assembly instances 101–
106.
XM-122 Assembly Instance 101 Data Format
Byte Definition
0–3 Channel 1 Overall measurement value
4–7 Channel 2 Overall measurement value
8–11 Channel 1 Gap measurement value
12–15 Channel 2 Gap measurement value
16–19 Current Speed measurement value
20–23 Peak Speed measurement value
24–27 Channel 1 Band 1 measurement value
28–31 Channel 2 Band 1 measurement value
32–35 Channel 1 Band 2 measurement value
36–39 Channel 2 Band 2 measurement value
40–43 Channel 1 Band 3 measurement value
44–47 Channel 2 Band 3 measurement value
48–51 Channel 1 Band 4 measurement value
52–55 Channel 2 Band 4 measurement value
56–59 Channel 1 1X Vector Magnitude measurement value
60–63 Channel 1 1X Vector Phase measurement value
64–67 Channel 2 1X Vector Magnitude measurement value
68–71 Channel 2 1X Vector Phase measurement value
72–75 Channel 1 2X Vector Magnitude measurement value
76–79 Channel 1 2X Vector Phase measurement value
80–83 Channel 2 2X Vector Magnitude measurement value
84–87 Channel 2 2X Vector Phase measurement value
88–91 Channel 1 3X Vector Magnitude measurement value
92–95 Channel 2 3X Vector Magnitude measurement value
96–99 Channel 1 Not 1X measurement value
100–103 Channel 2 Not 1X measurement value
104–107 Channel 1 gSE Overall measurement value
108–111 Channel 2 gSE Overall measurement value
112–115 Channel 1 Sum Harmonics measurement value
116–119 Channel 2 Sum Harmonics measurement value
120–123 Acceleration measurement value
