Publication GMSI10-UM013D-EN-P - May 2010

DeviceNet Objects 137

Instance Attributes

Services

1

Attributes can only be set while the device is in Program Mode. See the description of the Device Mode Object
for more information.

6

gSE Overall Measurement 2 gSE Overall measurement for Channel 2

7

Sum Harmonics
Measurement 1

Sum Harmonics measurement for Channel 1

8

Sum Harmonics
Measurement 2

Sum Harmonics measurement for Channel 2

Table C.26 Analog Input Point Object Instances

Instance

Name

Description

Table C.27 Analog Input Point Object Class Attributes

Attr ID

Access
Rule

Name Data

Type

Description

Semantics

3

Get

Value

REAL

4

Get

Status

BOOL

Indicates if a fault or
alarm has occurred.

0 = Operating without alarms or
faults
1 = Alarm or fault condition
exists. The Value attribute may
not represent the actual field
value.

8

Get

Value Data Type USINT

Determines the data type
of the Value.

1 = REAL

147

Get

Data Units

ENGUNIT

The units context of the
Value attribute.

See DeviceNet Specification
Volume 1 Appendix K.

Table C.28 Analog Input Point Object Services

Service
Code

Class/Instance Usage

Name

Description

0E

h

Class/Instance

Get_Attribute_Single

Returns the contents of the
specified attribute.

10

h

Instance

Set_Attribute_Single

Sets the contents of the
specified attribute.

1
