Publication GMSI10-UM013D-EN-P - May 2010
158 DeviceNet Objects
Overall Measurement
Object
(Class ID 322
H
)
The Overall Measurement Object models the measurement of the amplitude
of a signal including a wide frequency range.
Class Attributes
The Overall Measurement Object provides no class attributes.
Instances
There are 2 instances of this object.
Instance Attributes
16
h
Instance
Save
Validate the device
configuration settings if
necessary and save them to
non-volatile memory.
09
h
Instance
Delete
Delete the saved
configuration from
non-volatile memory.
15
h
Instance
Restore
Load the saved
configuration or the factory
default configuration from
non-volatile memory.
Table C.46 Device Mode Object Services
Service
Code
Class/Instance Usage
Name
Description
Table C.47 Overall Measurement Object Instance Attributes
Attr ID
Access
Rule
Name Data
Type
Description
Semantics
3
Get
Overall Value
REAL
Measured value
The output value of the
measurement performed by the
Overall Measurement Object on
the input signal. The result of
the measurement process
specified by Measurement is
converted to the units specified
by Data Units to produce the
Overall Value.
