Publication GMSI10-UM013D-EN-P - May 2010

DeviceNet Objects 171

Services

1

Attributes can only be set while the device is in Program Mode. See the description of the Device Mode Object
for more information.

Tachometer Channel Object
(Class ID 326

H

)

The Tachometer Channel Object models "front end" processing performed
on a tachometer signal before specific measurements are performed.

Class Attributes

The Tachometer Channel Object provides no class attributes.

5

Get

Maximum
Speed

REAL

The maximum (peak)
measured speed value
(positive or negative)
since the most recent
reset.

CPM

12

Get/Set

Time Constant

UINT

The time constant value
used for exponential
averaging of the Speed
Value
(a low pass
filter/output smoothing
filter).

Milliseconds

13

Get

Acceleration

REAL

The rate of change of the
Speed Value.

CPM/min

Table C.58 Speed Measurement Object Instance Attributes

Attr ID

Access
Rule

Name Data

Type

Description

Semantics

Table C.59 Speed Measurement Object Services

Service
Code

Class/Instance Usage

Name

Description

05

h

Instance

Reset

Clears Maximum (Peak)
speed to 0.

0E

h

Instance

Get_Attribute_Single

Returns a single attribute.

10

h

Instance

Set_Attribute_Single

Sets a single attribute.

1
