132 DeviceNet Objects
Table C.17 Instance 199 Component Mapping
EPATH (where ii =
instance number) Class
Name Class
Number Instance
Number Attribute
Name Attribute
Number Data
Type
21 1D 03 24 ii 30 04 Alarm 31D
h
1 - 16 Alarm Enable 4 BOOL
21 1D 03 24 ii 30 05 Alarm 31D
h
1 - 16 Type 5 USINT
21 1D 03 24 ii 30 07 Alarm 31D
h
1 - 16 Condition 7 USINT
21 1D 03 24 ii 30 08 Alarm 31D
h
1 - 16 Alert Threshold (High) 8 REAL
21 1D 03 24 ii 30 09 Alarm 31D
h
1 - 16 Danger Threshold
(High) 9 REAL
21 1D 03 24 ii 30 0A Alarm 31D
h
1 - 16 Alert Threshold Low 10 REAL
21 1D 03 24 ii 30 0B Alarm 31D
h
1 - 16 Danger Threshold Low 11 REAL
21 1D 03 24 ii 30 0C Alarm 31D
h
1 - 16 Hysteresis 12 REAL
21 1D 03 24 ii 30 0D Alarm 31D
h
1 - 16 Threshold (Set Point)
Multiplier 13 REAL
21 1D 03 24 ii 30 0E Alarm 31D
h
1 - 16 Startup Period 14 UINT
21 1D 03 24 ii 30 0F Alarm 31D
h
1 - 16 Speed Range Enable 15 BOOL
21 1D 03 24 ii 30 10 Alarm 31D
h
1 - 16 Speed Range High 16 REAL
21 1D 03 24 ii 30 11 Alarm 31D
h
1 - 16 Speed Range Low 17 REAL
21 0F 00 24 ii 30 01 Param 0F
h
10 - 25 Measurement
Identifier 1 USINT
21 1D 03 24 ii 30 14 Alarm 31D
h
1 - 16 Inhibit Tach Fault 20 BOOL
21 23 03 24 ii 30 04 Relay 323
h
1 - 5 Relay Enable 4 BOOL
21 23 03 24 ii 30 05 Relay 323
h
1 - 5 Latch Enable 5 BOOL
21 23 03 24 ii 30 06 Relay 323
h
1 - 5 Failsafe Enable 6 BOOL
21 23 03 24 ii 30 07 Relay 323
h
1 - 5 Delay 7 UINT
21 23 03 24 ii 30 09 Relay 323
h
1 - 5 Alarm Level 9 BYTE
21 0F 00 24 ii 30 01 Param 0F
h
26 - 30 Parameter Value
(Alarm Identifier A) 1 USINT
21 0F 00 24 ii 30 01 Param 0F
h
31 - 35 Parameter Value
(Alarm Identifier B) 1 USINT
21 23 03 24 ii 30 0C Relay 323
h
1 - 5 Logic 12 USINT
21 23 03 24 ii 30 0E Relay 323
h
1 - 5 Relay Installed 14 BOOL
