Publication GMSI10-UM013D-EN-P - May 2010
90 Configuration Parameters
Not 1X and Vector Status (XM
Serial Configuration Utility only) States whether a fault condition exists on the
associated channel. If a fault exists, the not 1X and
vector measurements may not be accurate.
The following conditions can cause a fault:
•
a transducer fault on the associated channel
•
no tachometer signal or a transducer fault exists
on the tachometer channel
•
the machine speed changes too fast for the
tracking algorithm to keep up or if the frequency of
FMAX goes outside the range of 10 to 5000Hz
Possible status values: No Fault
Fault
Not 1X Value Shows the magnitude of the vibration excluding the
vibration at the machine speed. The tachometer must be enabled
(Pulses Per Revolution set to 1 or
more), and a tachometer signal must
be present.
1X Magnitude The magnitude of the vibration at the machine
speed.
1X Phase The phase of the vibration at the machine speed.
2X Magnitude The magnitude of the vibration at two times the
machine speed.
2X Phase The phase of the vibration at two times the machine
speed.
3X Magnitude The magnitude of the vibration at three times the
machine speed.
Ch1/Ch2 Spectrum/Waveform
Status (XM Serial Configuration
Utility only) States whether a fault condition exists on the
associated channel. If a fault exists, the
spectrum/waveform data may not be accurate.
The following conditions can cause a fault:
•
a transducer fault on the associated channel
•
Sampling Mode set to "Synchronous" and there
is no tachometer signal or there is a fault on the
tachometer channel
Possible status values: No Fault
Fault
Get Waveform Data Only (XM
Serial Configuration Utility only) Controls whether the spectrum is calculated by the
Configuration Utility or the Vibration module. Check to upload only waveform data
from the module. The Configuration
Utility calculates and displays the
spectrum using the collected
waveform data.
Clear to upload both the waveform
and spectrum data from the module.
States whether a fault condition (no tachometer
signal or transducer fault) exists on the tachometer
channel. If a fault exists, the speed value may not be
accurate. Possible status values: No Fault
Fault
Monitor Data Parameters
Parameter Name Description Values/Comments
XM Configuration
Utility EDS File
Speed Status Transducer 3
Status
