Publication GMSI10-UM013D-EN-P - May 2010
DeviceNet Objects 141
10 No Alarm 1 Measurement
Identifier USINT 0 = CH 1 Overall
1 = CH 2 Overall
2 = CH 1 Gap
3 = CH 2 Gap
4 = CH 1 Band 1
5 = CH 2 Band 1
6 = CH 1 Band 2
7 = CH 2 Band 2
8 = CH 1 Band 3
9 = CH 2 Band 3
10 = CH 1 Band 4
11 = CH 2 Band 4
12 = Speed
14 = CH 1 1X Mag.
15 = CH 2 1X Mag.
16 = CH 1 2X Mag.
17 = CH 2 2X Mag.
18 = CH 1 3X Mag.
19 = CH 2 3X Mag.
20 = CH 1 Not 1X
21 = CH 2 Not 1X
22 = CH 1 Sum Harmonics
23 = CH 2 Sum Harmonics
24 = CH 1 1X Phase
25 = CH 2 1X Phase
26 = CH 1 2X Phase
27 = CH 2 2X Phase
29 = Acceleration
30 = CH1 gSE Overall
31 = CH2 gSE Overall 0
11 No Alarm 2 Measurement
Identifier USINT (same as above) 1
12 No Alarm 3 Measurement
Identifier USINT (same as above) 0
13 No Alarm 4 Measurement
Identifier USINT (same as above) 1
14 No Alarm 5 Measurement
Identifier USINT (same as above) 0
15 No Alarm 6 Measurement
Identifier USINT (same as above) 1
16 No Alarm 7 Measurement
Identifier USINT (same as above) 0
17 No Alarm 8 Measurement
Identifier USINT (same as above) 1
18 No Alarm 9 Measurement
Identifier USINT (same as above) 0
19 No Alarm 10 Measurement
Identifier USINT (same as above) 1
Table C.30 Parameter Object Instances
Instance
Read
Only
Name Data Type Valid Values Default Value
