20 ma output parameters – Rockwell Automation 1440-VSE02-01RA XM-122 gSE Vibration Module User Manual
Page 92

Publication GMSI10-UM013D-EN-P - May 2010
82 Configuration Parameters
4-20 mA Output Parameters
The 4-20 mA output parameters define the characteristics of the two 4-20 mA
output signals. The parameters are the same for each output.
4-20 mA Parameters
Parameter Name
Description
Options/Comments
Enable
Enables/disables the 4-20 mA output.
Measurement
Sets the type of measurement and the channel that
the 4-20 mA output signal will track.
Options: Ch1 / Ch2 Overall
Ch1 / Ch2 Gap
Ch1 / Ch2 Band 1–4
Speed
Ch1 / Ch2 1X Mag
Ch1 / Ch2 2X Mag
Ch1 / Ch2 3X Mag
Ch1 / Ch2 Not 1X
Ch1 / Ch2 Sum Harmonics
Acceleration
Ch1 / Ch2 gSE Overall
Min Range
The measured value associated with the 4 mA.
Same measurement unit as Output
Data Unit selection for the specified
channel.
Max Range
The measured value associated with the 20 mA.
XM Configuration
Utility
EDS File
Check to enable
Enabled
Clear to disable
Disabled
IMPORTANT
Measured values between Min Range and Max Range are
scaled into the range from 4.0 to 20.0 to produce the
output value. The Min Range value does not have to be
less than the Max Range value. If the Min Range value is
greater than the Max Range value, then the output signal
is effectively inverted from the input signal.
