Publication GMSI10-UM013D-EN-P - May 2010

DeviceNet Objects 175

Instances

There are 6 instances of this object.

Instance Attributes

Table C.64 Vector Measurement Object Instances

Instance

Description

1

Channel 1 1X Vector Measurement

2

Channel 2 1X Vector Measurement

3

Channel 1 2X Vector Measurement

4

Channel 2 2X Vector Measurement

5

Channel 1 3X Vector Measurement

6

Channel 2 3X Vector Measurement

Table C.65 Vector Measurement Object Instance Attributes

Attr ID

Access
Rule

Name Data

Type

Description

Semantics

3

Get

Magnitude
Value

REAL

The measured magnitude
value.

4

Get

Phase Value

REAL

The measured phase
value.

Degrees

Note: Note valid for instances 5
and 6.

5

Get

Status

BOOL

Indicates if a fault or
alarm has occurred.

0 = Operating without alarms of
faults.
1 = Alarm or fault condition
exists. The Value attributes
may not represent the actual
field value.
