Configuration Parameters 61
Channel Signal Processing Parameters
Parameter Name Description Values/Comments
Output Data Unit The data units of the measured values. The available options depend on the
Eng. Units selection. See page
58.
Very Low HPF Frequency (EDS
File only) Shows the corner frequency for the Very Low high
pass filter option.
Low HPF Frequency (EDS File
only) Shows the corner frequency for the Low high pass
filter option.
Medium HPF Frequency (EDS File
only) Shows the corner frequency for the Medium high
pass filter option.
High HPF Frequency (EDS File
only) Shows the corner frequency for the High high pass
filter option.
Very High HPF Frequency (EDS
File only) Shows the corner frequency for the Very High high
pass filter option.
High Pass Filter Sets the high pass filter to apply to the
measurements. The high pass filter is useful in
removing low frequency signal components that
would dominate the signal. The high pass filter
attenuates all frequencies below a defined
frequency. It allows, or passes, frequencies above
the defined frequency. Important: Select the Bypass option
when you want a more accurate
representation of dynamic signals at
low frequencies. This option reduces
the distortion of the waveform at low
frequencies and reduces attenuation
at lower frequencies.
Note: The lowest frequency high pass
filter is not available for integrated
measurements.
Eng. Units
Output Data
Unit Options
g g
ips
mil
mm/sec
um
ips or mm/sec ips
mil
mm/sec
um
mils or um mils
um
Volt volt
Pa or psi Pa
psi
