Alarm Parameters The Alarm parameters control the operation of the alarms (alert and danger
level) and provide alarm status. The XM-122 provides 16 alarms. The alarms
are not restricted to a channel, but the maximum number of alarms that can be
assigned to any one measurement is eight. Use the parameters to configure
which measurement the alarm is associated with, as well as the behavior of the
alarm.
Alarm Parameters
Parameter Name Description Values/Comments
Number (1-16) (XM Serial
Configuration Utility only) Sets the alarm to be configured in the XM Serial
Configuration Utility. There are 16 alarms in the
XM-122. The alarms are not restricted to a channel. Select a number from 1 to 16.
Name (XM Serial Configuration
Utility only) A descriptive name to identify the alarm in the XM
Serial Configuration Utility. Maximum 18 characters
Enable Enable/disable the selected alarm.
Note: The Alarm Status is set to "Disarm" when the
alarm is disabled.
Measurement The type of measurement and the channel that is
associated with the alarm.
Note: A maximum of eight alarms can be associated
with any one measurement.
Options: Ch1 / Ch2 Overall
Ch1 / Ch2 Gap
Ch1 / Ch2 Band 1–4
Speed
Ch1 / Ch2 1X Mag
Ch1 / Ch2 2X Mag
Ch1 / Ch2 3X Mag
Ch1 / Ch2 Not 1X
Ch1 / Ch2 Sum Harmonics
Ch1 / Ch2 1X Phase
Ch1 / Ch2 2X Phase
Acceleration
Ch1 / Ch2 gSE Overall
Alarm Type (EDS File only) Controls whether the alarm is used as a magnitude
or vector (phase) alarm.
•
Magnitude Alarms - The measurement value is
compared against the threshold values on a linear
scale.
•
Vector (Phase) Alarms - The measurement value
is compared against the threshold values on a
circular scale of 0 to 360 degrees.
Options: Magnitude
Vector
XM Configuration
Utility EDS File
Check to Enable Enabled
Clear to Disable Disabled
