A-2 Catalog Number Explanation – Drive Selection
7000-UM150I-EN-P – June 2013 7000 “B” Frame
Table A-2
Service Duty Rating, Continuous Current Rating and Altitude Rating Code
Service Duty Rating and Altitude Rating Code
Continuous Current Capability
Code Rating
A = Normal Duty
0-1000 m Altitude (@ 40°C Ambient)
B = Normal Duty
1001-5000 m Altitude
(2000 m Altitude @ 37.5°C Ambient)
(3000 m Altitude @ 35.0°C Ambient)
(4000 m Altitude @ 32.5°C Ambient)
(5000 m Altitude @ 30.0°C Ambient)
C = Heavy Duty
0-1000 m Altitude
D = Heavy Duty
1001-5000 m Altitude
(2000 m Altitude @ 37.5°C Ambient)
(3000 m Altitude @ 35.0°C Ambient)
(4000 m Altitude @ 32.5°C Ambient)
(5000 m Altitude @ 30.0°C Ambient)
Z = Custom Configuration (Contact Factory)
40 40 Amp
46 46 Amp
53 53 Amp
61 61 Amp
70 70 Amp
81 81 Amp
93 93 Amp
105 105 Amp
120 120 Amp
140 140 Amp
160 160 Amp
185 185 Amp
215 215 Amp
250 250 Amp
285 285 Amp
325 325 Amp
375 375 Amp
430 430 Amp
Table A-3
Nominal Line Voltage, Control Voltage, System Frequency
Voltage
Frequency
(Hz)
Modification Number
(Externally Supplied
Control Power)
Nominal
Line
Control
(3 phase)
2400
208
60
AHD
480 ABD
600 ACD
3300
230
50
CPD
380 CND
400 CKD
4160
230 EPD
380 50 END
208
60
EHD
480 EBD
600 ECD
6600
230
50
JPD
380 JND
400 JKD
