Appendix
A
7000 “B” Frame
7000-UM150I-EN-P – June 2013
Catalog Number Explanation
for PowerFlex 7000 MV Drives
7000 - A105 D EHD - R18TX - 1
– 1DD – 3LL – 760A
First
Position
Second
Position
Third
Position
Fourth
Position
Fifth
Position
Sixth
Position
Bulletin
Number
(Refer to
TABLE A-1)
Service Duty /
Continuous
Current Rating /
Altitude Rating
Code
(Refer to
TABLE A-2)
Enclosure
Type
D = NEMA Type 1
w/gaskets and vents
(IEC IP42)
Nominal Line Voltage
Control Voltage
System Frequency
(Reference
TABLE A-3)
Rectifier
Type Code
R6TX
R6LR
R18TX
RPLR
RPTX
RPDTD
Options
R6TX – 6-pulse rectifier for connection to remote transformer
R6LR – 6-pulse rectifier with integral line reactor
R18TX – 18-pulse rectifier for connection to remote transformer
RPLR – PWM rectifier with integral line reactor
RPTX – PWM rectifier for connection to remote transformer
RPDTD – Direct-to-Drive Technology
Table A-1
Catalog Number Descriptions
Catalog Number
Description
7000A
PowerFlex 7000 “A” Frame Variable Frequency AC Drive, Air-cooled
7000
PowerFlex 7000 “B” Frame Variable Frequency AC Drive, Air-cooled
7000L
PowerFlex 7000 “C” Frame Variable Frequency AC Drive, Liquid-cooled
