Overview of Drive 1-11
7000 “B” Frame
7000-UM150I-EN-P – June 2013
Description
NEMA
IEC
Control Power
208-575 V, 3 Phase, 50/60 Hz
External I/O
16 Digital Inputs, 16 Digital Outputs
External Input Ratings
50-60 Hz AC or DC
120-240 V – 1 mA
External Output Ratings
50-60 Hz AC or DC
30-260 V – 1 Amp
Analog Inputs
(1) Isolated, (1) Non-isolated, 4-20 mA or 0-10 V (250 ohm)
Analog Resolution
• Analog input 12 Bit (4-20 mA)
• Internal parameter 32 Bit resolution
• Serial Communication 16 Bit resolution (.1Hz)
(Digital Speed Reference)
Analog Outputs
(1) Isolated, (7) Non-isolated,
4-20 mA or 0-10 V (600 ohm)
Communication Interface
SCANPort /DPI
Scan Time
Internal ScanPort – 10 ms
Internal DPI – 5 ms
Communications Protocols
(Optional)
RS232/422/485
Ethernet
DH485
Interbus
Remote I/O
LON Works
DeviceNet
Can Open
ControlNet
Profibus
Modbus/Modbus Plus
Johnson Controls
Enclosure
NEMA 1
IP21
Lifting Device
Standard / Removable
Mounting Arrangement
Mounting Sill channels
Structure Finish
Epoxy Power – Paint
Exterior Sandtex Light Grey (RAL 7038) – Black (RAL 8022)
Internal – Control Sub Plates – High Gloss White (RAL 9003)
Interlocking
Key provision for customer input Disconnecting Device
Corrosion Protection
Unpainted Parts (Zinc Plated / Bronze Chromate)
Ambient Temperature
0° to 40°C (32°F to 104°F)
Fiber Optic Interface
Rectifier – Inverter – Cabinet (Warning / Trip)
Door Filter
Painted Diffuser with Matted Filter Media
Door Filter Blockage
Air Flow Restriction (Trip / Warning)
Storage and Transportation
Temperature Range
-40°C to 70°C (-40°F to 185°F)
Relative Humidity
Max. 95% Non-Condensing
Altitude (Standard)
0 to 1000 m (0 to 3300 ft.)
Altitude (Optional)
1001 to 5000 m (0 to 16400 ft.)
Seismic (UBC Rating)
1, 2, 3, 4
