Publication 1793-6.5.1 - April 1999
Specifications A-5
Accuracy Drift
Voltage Terminal
Current Terminal 0.0045% FS per o C
0.0069% FS per o C
Isolation Voltage Channel to system - 850V dc for 1s
Channel to channel - None
General
Flexbus Current 20mA maximum
Power Dissipation 2.5W @ 31.2V dc
Thermal Dissipation 8.5 BTU/hr @ 31.2V dc
Indicators 1 green power indicators
External dc Power Voltage
Current
19.2-31.2V dc (5% ac ripple)
100mA maximum
Dimensions in
(mm)
2.72H x 3.15D x 2.17W
(69H x 80D x 55W)
Environmental Conditions
Operational Temperature
Storage Temperature
Relative Humidity
Shock
Operating
Nonoperating
Vibration
0 to +55 o C (32 to +131 o F)
-40 to +85
o
C (-40 to +185
o
F)
5 to 95% noncondensing
Tested to 30g peak acceleration, 11(+1)ms pulse width
Tested to 50g peak acceleration, 11(+1)ms pulse width
Tested 5g @ 10-500Hz per IEC68-2-6
Conductors Wire Size
Category
12 gauge (4mm 2 ) stranded wire
3/64 in (1.2mm) maximum insulation
2
Agency Certification
(when product is marked) • CSA certified
• CSA Class 1, Division 2 Groups A, B, C and D certified
• UL listed
• CE marked for all applicable directives
Publications • Installation Instructions - 1793-5.7
• User Manual - 1793-6.5.1
1 Use this category information for planning conductor routing as described in publication
1770-4.1, “Wiring and Grounding Guidelines for Noise Immunity.”
Specifications - 2 Input/1 Output Analog Module, Cat. No. 1793-IE2XOE1 and -IE2XOE1S
