Publication 1793-6.5.1 - April 1999

1-2

Overview of FLEX Integra and your Analog Modules

Types of FLEX Integra Modules

We describe the following FLEX Integra Analog modules in this user
manual:

FLEX Integra analog input, output and combination modules are block
transfer modules that interface analog signals with any Allen-Bradley
programmable controllers that have block transfer capability. Block
transfer programming moves input from the module’s memory to a
designated area in the processor data table, and output data words from a
designated area in the processor data table to the module’s memory. Block
transfer programming also moves configuration words from the processor
data table to module memory.

The analog modules have selectable ranges as shown in the table below:

How FLEX Integra Analog
Modules Communicate with
Programmable Controllers

The adapter/power supply transfers data to the module (block transfer
write) and from the module (block transfer read) using BTW and BTR
instructions in your ladder diagram program. These instructions let the
adapter obtain input values and status from the module, and let you send
output values and establish the module’s mode of operation. Figure 1.1
describes the communication process.

Catalog Number

Voltage

Inputs

Outputs

Description

1793-IE4

24V dc

4

analog – 4 input, single-ended, non-isolated;
screw-cage connectors

1793-IE4S

24V dc

4

analog – 4 input, single-ended, non-isolated;
spring-clamp connectors

1793-OE2

24V dc

2

analog – 2 output, single-ended, non-isolated;
screw-cage connectors

1793-OE2S

24V dc

2

analog – 2 output, single-ended, non-isolated;
spring-clamp connectors

1793-IE2XOE1

24V dc

2

1

analog – 2 input, single-ended, non-isolated
and 1 output, single-ended, non-isolated;
screw-cage connectiors

1793-IE2XOE1S

24V dc

2

1

analog – 2 input, single-ended, non-isolated
and 1 output, single-ended, non-isolated;
spring-clamp connectors

Voltage

Current

0 to 10V dc

0 to 20mA

±10V dc

4 to 20mA
