Publication 1793-6.5.1 - April 1999
A-4 Specifications
Specifications - 2 Input/1 Output Analog Module, Cat. No. 1793-IE2XOE1 and -IE2XOE1S
Module Type 2 analog inputs, 1 analog output
1793-IE2XOE1 - 16 screw-cage terminals
1793-IE2XOE1S - 16 spring-clamp terminals
Module Location DIN rail mounting
Number of Channels 3 - 2 in, 1 out - nonisolated
Input
Resolution
Voltage
Current
12-bits - unipolar; 11-bit plus sign - bipolar
2.56mV/cnt unipolar; 5.13mV/cnt bipolar
5.13
μA/cnt
Data Type left justified 16-bit 2’s complement
Conversion Type Successive approximation
Conversion Rate 256 μs all channels
Input Current Terminal 4-20mA (user configurable)
0-20mA (user configurable)
Input Voltage Terminal +10V (user configurable)
0-10V (user configurable)
Normal Mode Rejection Ratio
Voltage Terminal
Current Terminal
-3db @ 17Hz; -20db/decade
-10db @ 50Hz; -11.4db @ 60Hz
-3db @ 17Hz; -20db/decade
-15.3db @ 50Hz; -16.8db @ 60Hz
Step Response to 63%
Voltage Terminal
Current Terminal 9.4ms
18.2ms
Impedance
Voltage Terminal
Current Terminal 9.4ms100K Ω; 200K Ω @ dc
238 Ω
Absolute Accuracy
Voltage Terminal
Current Terminal
0.20% FS @ 25
o
C
0.20% FS @ 25 o C
Accuracy Drift
Voltage Terminal
Current Terminal 0.00428% FS per o C
0.00407% FS per o C
Maximum Overload
Voltage Terminal
Current Terminal
Single channel, continuous
30V
32mA
Output
Resolution
Voltage
Current
12-bits plus sign
2.56mV/cnt
5.13
μA/cnt
Data Type left justified 16-bit 2’s complement
Conversion Type Pulse width modulation
Conversion Rate 1.024ms all channels
Current Terminal 4-20mA (user configurable)
0-20mA (user configurable)
Voltage Terminal +10V (user configurable)
0-10V (user configurable)
3A maximum
Step Response to 63%
Voltage Terminal
Current Terminal 24ms
24ms
Impedance
Voltage Terminal
Current Terminal 15-750 Ω resistive
15-750 Ω resistive
Absolute Accuracy
Voltage Terminal
Current Terminal 0.133% FS @ 25 o C
0.425% FS @ 25 o C
