Chapter summary – Rockwell Automation 1793-OE2S FLEX INTEGRA ANALOG MOD User Manual
Page 28
Publication 1793-6.5.1 - April 1999
3-6
Module Programming
Refer to Appendix B for a table of values for various current and voltage
modes.
Appendix B also includes an example of scaling.
Chapter Summary
In this chapter, you learned how to program your programmable controller.
You were given sample programs for your PLC-3 and PLC-5 family
processors.
