5-6 How Communication Takes Place and I/O Image Table Mapping with the DeviceNet Adapter
2 Output Analog Module (Cat. No. 1793-OE2 and -OE2S)
Analog Output Module (1793-OE2 and -OE2S) Read
Bit/Word Descriptions for the 1793-OE2 and -OE2S Analog Output Module Read
Module Image
I/O Image
Analog Data Channel 0
Analog Data Channel 1
Not used
Not used Not used
Not used
Not used
Not used
Not used
Not used
Diagnostics
Config. Select Full Range
Input Size
Output Size
0 or 1 Word
1 to 14 Words
Read
Write
M
PU
Reserved
Reserved
Not used
Not used
Not used
Not used
Word/Dec. Bit 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Word/Octal Bit 17 16 15 14 13 12 11 10 07 06 05 04 03 02 01 00
Read Word 1 PU Not used – set to 0 W1 W0
Where: W = Diagnostic bits for current output wire broken or load resistance high. (Not used on voltage outputs.)
PU = Power up bit
Word
Decimal Bit
(Octal Bit)
Definition
Read
Word 1
Bits 00-01
Current outputs only – When set (1), the wire on the output is broken or the
load resistance is too high. Bit 00 corresponds to channel 0, bit 01
corresponds to channel 2, and so on.
Bits 02-14
(02-16)
Not used – set to 0
Bit 15 (17)
Power Up bit. - This bit is set to 1 when all bits in the configuration
register (write word 5) are 0 (unconfigured state). The configuration
register can be cleared by either a reset, or by the user writing all zeroes to it.
