Publication 1793-6.5.1 - April 1999
A-2
Specifications
Specifications - 4 Input Analog Module, Cat. No. 1793-IE4 and -IE4S
Thermal Dissipation
3.4 BTU/hr @ 31.2V dc
Indicators
1 green power indicators
External dc Power Voltage
Current
19.2-31.2V dc (5% ac ripple)
60mA maximum
Dimensions
in
(mm)
2.72H x 3.15D x 2.17W
(69H x 80D x 55W)
Environmental Conditions
Operational Temperature
Storage Temperature
Relative Humidity
Shock
Operating
Nonoperating
Vibration
0 to +55
o
C (32 to +131
o
F)
-40 to +85
o
C (-40 to +185
o
F)
5 to 95% noncondensing
Tested to 30g peak acceleration, 11(+1)ms pulse width
Tested to 50g peak acceleration, 11(+1)ms pulse width
Tested 5g @ 10-500Hz per IEC68-2-6
Conductors
Wire Size
Category
12 gauge (4mm
2
) stranded wire
3/64 in (1.2mm) maximum insulation
2
Agency Certification
(when product is marked)
• CSA certified
• CSA Class 1, Division 2 Groups A, B, C and D
certified
• UL listed
• CE marked for all applicable directives
User Manual
• Publication 1793-6.5.1
1
Use this category information for planning conductor routing as described in publication
1770-4.1, “Wiring and Grounding Guidelines for Noise Immunity.”
