Writing Configuration to and Reading Status from Your Module with a Remote I/O Adapter 4-11
Chapter Summary In this chapter you learned how to configure your module’s features and
enter your data.
Words 4
and 5
Not used – set to 0.
Word 6
Bits 00-14
(00-16)
Channel 0 Safe State analog value – 12-bit left justified two’s complement number;
unused lower bits are zero; 4-20mA uses all 16 bits.
Bits 15 (17) Channel 0 Safe State analog data sign bit.
Word 7
Bits 00-14
(00-16)
Channel 1 Safe State analog value – 12-bit left justified two’s complement number;
unused lower bits are zero; 4-20mA uses all 16 bits.
Bits 15 (17) Channel 1 Safe State analog data sign bit.
Word
Decimal Bit
(Octal Bit)
Definition
