Publication 1793-6.5.1 - April 1999
How Communication Takes Place and I/O Image Table Mapping with the DeviceNet Adapter 5-3
System Throughput System throughput, from analog input to backplane, is a function of:
• the data format selected
• the type and mode of sensors selected
• whether filtering is selected
The A/D converter which converts channel 0 through 7 analog data to a
digital word provides a programmable single low pass filter. You can set the
frequency of this filter during module configuration. The selection
influences the A/D output data rate, thus affecting system throughput.
Mapping Data into the
Image Table FLEX Integra analog input module data table mapping is shown below.
4 Input Analog Module (Cat. No. 1793-IE4 and -IE4S)
Module Image
I/O Image
Input Data Channel 0
Input Data Channel 1
Input Data Channel 2
Input Data Channel 3
Underrange
Configure select
Input Size
Output Size
0 or 6 Words
1 to 9 Words
PU
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
