Publication 1793-6.5.1 - April 1999

6-8

Input, Status, Output and Configuration Files using ControlNet

ABit/Word Descriptions for the 1793-OE2 and -OE2S Analog Output Module Read

Range Selection Bits for the 1793-OE2 and -OE2S Analog Output Module (Word 5)

Output Word/Bit Descriptions for the 1793-OE2 and -OE2S Analog Output Module
Write

Input

Words

Decimal Bit

(Octal Bit)

Definition

Read

Word 0

Bits 00-01

Current outputs only – When set (1), the wire on the output is broken or the
load resistance is too high. Bit 00 corresponds to channel 0, bit 01
corresponds to channel 2, and so on.

Bits 02-14

(02-16)

Not used – set to 0

Bit 15 (17)

Power Up bit. - This bit is set to 1 when all bits in the configuration
register (write word 5) are 0 (unconfigured state).
The configuration
register can be cleared by either a reset, or by the user writing all zeroes to it.

Channel No.

Channel 0

Channel 1

F0

C0

F1

C1

Decimal Bits (Octal Bits)

00

08 (10)

01

09 (11)

4-20mA

0

1

0

1

0-10V dc/0-20mA

1

0

1

0

–10 to +10V dc

1

1

1

1

Off

1

0

0

0

0

C = Configure select bit
F = Full range bit

1

When configured to off, individual channels will send 0V or 0mV.

Output Word

Decimal Bit

(Octal Bit)

Definition

Configuration

Word 0

Bits 00-14

(00-16)

Channel 0 analog data – 12-bit left justified two’s complement number; unused
lower bits are zero; 4-20mA uses all 16 bits.

Bits 15 (17)

Channel 0 analog data sign bit.

Word 1

Bits 00-14

(00-16)

Channel 1 analog data – 12-bit left justified two’s complement number; unused
lower bits are zero; 4-20mA uses all 16 bits.

Bits 15 (17)

Channel 1 analog data sign bit.

Word 2

Bits 00-14

(00-16)

Channel 2 analog data – 12-bit left justified two’s complement number; unused
lower bits are zero; 4-20mA uses all 16 bits.

Bits 15 (17)

Channel 2 analog data sign bit.

Word 3

Bits 00-14

(00-16)

Channel 3 analog data – 12-bit left justified two’s complement number; unused
lower bits are zero; 4-20mA uses all 16 bits.

Bits 15 (17)

Channel 3 analog data sign bit.
