Page 51: Enhanced redundancy system quick start, Chapter 3, Chapter

Rockwell Automation Publication 1756-UM535D-EN-P - November 2012
51
Chapter
3
Install the Enhanced Redundancy System
Before You Begin
Complete these tasks before you install the enhanced redundancy system:
• Verify that you have the components required to install your system.
• Read and understand the safety and environmental considerations
explained in each component’s installation instruction publication.
• Order a 1756-RMC
x fiber-optic communication cable if you do not have
one.
• If you choose to make your own fiber-optic cable for lengths not supported
by 1756-RMC
x catalog numbers, refer to
Enhanced Redundancy System Quick Start
Refer to these Quick Start steps when setting up your system for the first time.
1. Install/update the workstation software and firmware bundle. (Refer
Step 1: Install the Software on page 53
Software applications needed include:
• RSLogix 5000 software
• RSLinx Classic communication software
• Redundancy Module Configuration Tool (RMCT). See
Topic
Page
Install an Enhanced Redundancy System
Step 3: Connect the Redundancy Modules via a Fiber-optic Cable
Step 4: Update Redundant Chassis Firmware
Step 5: Designate the Primary and Secondary Chassis
IMPORTANT
If RSLinx Classic software is already on your system, make sure to shut it down
before installing/upgrading software.
