Status Indicators
Appendix A
describes the alphanumeric codes.
The fault code is a four-character alphanumeric string. Valid characters are 0
…
9
and A through Z, except S and O. The first character is always E. Each firmware
subsystem within the redundancy module is assigned a range of fault codes. Each
subsystem assigns fault codes within its range.
If you encounter one of these error codes, record the Exxx code and contact
Rockwell Automation Technical Support.
Recovery Messages
For certain faults, the module status display provides recovery instructions. Up to
four, four-character words are displayed.
Table 48 - Alphanumeric Error Codes
Valid Character String
Indication
E
Error.
x
1
The subsystem in which the error was detected.
x
2
The subsystem function or group of functions in which the error was detected.
x
3
The specific error.
Range
Subsystem
Range
Subsystem
E 0 _ _
Back-up Control Object
E C _ _
Object Communication
E 1 _ _
OS Board Support Package
E D _ _
Wall Clock Time Object
E 2 _ _
Chassis Profile Object
E E _ _
Non-maskable Interrupt Service
Routine
E 3 _ _
Coordinated System Time Object
E F _ _
Nonvolatile Storage Object
E 4 _ _
Device Object
E G _ _
RM Fault Handler
E 5 _ _
Extended Log Object
E H _ _
Self Test Object
E 6 _ _
Event Log Object
E I _ _
Workstation Display Object
E 7 _ _
Back-up Communication Object
E J _ _
Industrial Control Platform Object
E 8 _ _
ICP Toolkit
E K _ _
RM Watchdog Manager
E 9 _ _
Indicator Device Driver
E L _ _
Instrumentation Object
E A _ _
RM State Machine
E M _ _
File Object
E B _ _
Event Log Device Driver
Table 49 - Recover Messages
Recovery Instruction Code
Description
RPLC MOD
Replace the module.
RSET MOD
Reset the module.
REMV MOD
Remove the module.
SEAT MOD
Reinsert the module into the chassis.
