Rockwell Automation Publication 1756-UM535D-EN-P - November 2012

265

Appendix

D

Convert from a Nonredundant System

When converting from a nonredundant to a redundant system, first consider the

following:

You can use only RSLogix 5000 software versions 16, 19, or 20 in an

enhanced redundancy system.

The redundant chassis pair has controller, communication module and

I/O module restrictions.

See

Chapter 1

for additional information.

Complete the tasks in this section to convert a nonredundant ControlLogix

system to an enhanced redundancy system.

Topic

Page

Update the Configuration in RSLogix 5000 Software

266

Replace Local I/O Tags

268

Replace Aliases to Local I/O Tags

269

Remove Other Modules from the Controller Chassis

270

Add an Identical Chassis

271

Upgrade to Enhanced Redundancy Firmware

271

Update the Controller Revision and Download the Project

271
