Page 118: Attempts log

118
Rockwell Automation Publication 1756-UM535D-EN-P - November 2012
Chapter 6
Configure the Redundancy Modules
Recent Synchronization Attempts Log
This table describes the possible result and causes of synchronization states.
If the Synchronization Attempts log indicates that the Synchronization attempt
was aborted, use this table to further interpret the cause.
Table 18 - Recent Synchronization Attempts Log - Result Interpretations
Result
Result Interpretation
Undefined
The result of the synchronization is unknown.
No attempt since last powerup
Synchronization has not been attempted since power was applied to
the module.
Success
Full synchronization was successfully completed.
Abort
The synchronization attempt failed. See the table
Synchronization Attempts Log - Result Interpretations
information.
Table 19 - Synchronization Interpretation
Cause
Cause Interpretation
Undefined
The cause of synchronization failure is unknown.
Module Pair Incompatible
Synchronization aborted because one or more module pairs are incompatible.
Module Configuration Error
Synchronization aborted because one of the modules is improperly configured.
Edit Session In Progress
Synchronization aborted because an edit or session is in progress.
Crossloading Failure
An undetermined failure occurred during synchronization between redundancy modules.
Comm Disconnected
The cable between the redundancy modules was disconnected.
Module Insertion
Synchronization aborted because a module was inserted into a chassis.
Module Removal
Synchronization aborted because a module was removed from a chassis.
Secondary Module Failed
Synchronization aborted because of a failure in the secondary module.
Incorrect Chassis State
Synchronization aborted due to an incorrect chassis state.
Comm Does Not Exist
Synchronization could not be performed because the communication link between redundancy modules does not exist.
Nonredundant Compliant Module Exists
Synchronization could not be performed because one or more nonredundancy modules are present in one of the chassis.
Sec Failed Module Exists
A module in the secondary chassis has asserted the SYS_FAIL line, indicating that it has faulted or failed.
Local Major Unrecoverable Fault
Synchronization was aborted because of a local major unrecoverable fault.
Partner Has Major Fault
Synchronization was aborted because the partner module has a major fault.
Sec SYS_FAIL_L Subsystem Failed
The test of the SYS_FAIL line in the secondary chassis failed.
Sec RM Device Status = Comm Error
Synchronization was aborted because the secondary redundancy module’s status indicates a communication error.
Sec RM Device Status = Major Recoverable
Fault
Synchronization was aborted because the secondary redundancy module’s status indicates a major recoverable fault.
Sec RM Device Status = Major Unrecoverable
Fault
Synchronization was aborted because the secondary redundancy module’s status indicates a major unrecoverable fault.
Incorrect Device State
Synchronization was aborted because the device is in the wrong state.
Primary Module Failed
Synchronization was aborted because of a failure in the primary module.
Primary Failed Module Exists
A module in the primary chassis has asserted the SYS_FAIL line, indicating that it has faulted or failed.
Auto-Sync Option
Synchronization was aborted because the Auto-Synchronization parameter of one of the redundancy modules was changed during
synchronization.
