Rockwell Automation 1403-NDNET DeviceNet Communications Card Installation Instructions - Manual (Page 99)

Publication 1403-IN054B-EN-P - August 2001
DeviceNet Data Tables B-69
304
5
th
harmonic
Float 4 See Instance 43, parameter 3 (% harmonic distortion for I1)
305
6
th
harmonic
Float 4 See Instance 41, parameter 4 (% harmonic distortion for I1)
306
7
th
harmonic
Float 4 See Instance 43, parameter 4 (% harmonic distortion for I1)
307
8
th
harmonic
Float 4 See Instance 41, parameter 5 (% harmonic distortion for I1)
308
9
th
harmonic
Float 4 See Instance 43, parameter 5 (% harmonic distortion for I1)
309
10
th
harmonic
Float 4 See Instance 41, parameter 6 (% harmonic distortion for I1)
310
11
th
harmonic
Float 4 See Instance 43, parameter 6 (% harmonic distortion for I1)
311
12
th
harmonic
Float 4 See Instance 41, parameter 7 (% harmonic distortion for I1)
312
13
th
harmonic
Float 4 See Instance 43, parameter 7 (% harmonic distortion for I1)
313
14 th harmonic
Float 4 See Instance 41, parameter 8 (% harmonic distortion for I1)
314
15
th
harmonic
Float 4 See Instance 43, parameter 8 (% harmonic distortion for I1)
315
16 th harmonic
Float 4 See Instance 41, parameter 9 (% harmonic distortion for I1)
316
17
th
harmonic
Float 4 See Instance 43, parameter 9 (% harmonic distortion for I1)
317
18 th harmonic
Float 4 See Instance 41, parameter 10 (% harmonic distortion for I1)
318
19
th
harmonic
Float 4 See Instance 43, parameter 10 (% harmonic distortion for I1)
319
20 th harmonic
Float 4 See Instance 41, parameter 11 (% harmonic distortion for I1)
320
21
st
harmonic
Float 4 See Instance 43, parameter 11 (% harmonic distortion for I1)
321
22 nd harmonic
Float 4 See Instance 42, parameter 1 (% harmonic distortion for I1)
322
23 rd harmonic
Float 4 See Instance 44, parameter 1 (% harmonic distortion for I1)
323
24 th harmonic
Float 4 See Instance 42, parameter 2 (% harmonic distortion for I1)
324
25 th harmonic
Float 4 See Instance 44, parameter 2 (% harmonic distortion for I1)
325
26 th harmonic
Float 4 See Instance 42, parameter 3 (% harmonic distortion for I1)
326
27 th harmonic
Float 4 See Instance 44, parameter 3 (% harmonic distortion for I1)
327
28 th harmonic
Float 4 See Instance 42, parameter 4 (% harmonic distortion for I1)
328
29
th
harmonic
Float 4 See Instance 44, parameter 4 (% harmonic distortion for I1)
329
30 th harmonic
Float 4 See Instance 42, parameter 5 (% harmonic distortion for I1)
330
31
st
harmonic
Float 4 See Instance 44, parameter 5 (% harmonic distortion for I1)
331
32 nd harmonic
Float 4 See Instance 42, parameter 6 (% harmonic distortion for I1)
332
33
rd
harmonic
Float 4 See Instance 44, parameter 6 (% harmonic distortion for I1)
333
34 th harmonic
Float 4 See Instance 42, parameter 7 (% harmonic distortion for I1)
334
35
th
harmonic
Float 4 See Instance 44, parameter 7 (% harmonic distortion for I1)
335
36 th harmonic
Float 4 See Instance 42, parameter 8 (% harmonic distortion for I1)
336
37
th
harmonic
Float 4 See Instance 44, parameter 8 (% harmonic distortion for I1)
337
38
th
harmonic
Float 4 See Instance 42, parameter 9 (% harmonic distortion for I1)
338
39
th
harmonic
Float 4 See Instance 44, parameter 9 (% harmonic distortion for I1)
339
40
th
harmonic
Float 4 See Instance 42, parameter 10 (% harmonic distortion for I1)
340
41
st
harmonic
Float 4 See Instance 44, parameter 10 (% harmonic distortion for I1)
341 FFT iteration Int 2 See Instance 42, parameter 13 (% harmonic distortion for I1)
Param # Parameter name Data type #bytes Comment
