Appendix
C
DeviceNet™ Communication Card Sample
Ladder Listing
Ladder Program
Description The following is a ladder program designed to return real- time data
from a 1403 Powermonitor II to an SLC 500 processor via DeviceNet
using a DeviceNet scanner module. The following example uses these
settings:
•
Node = 5
•
Port = 0
•
Class = 4
•
Instance = 11
•
Attribute = 3
Explicit Message Transfer
The Explicit Message Transfer Block header for this example is
assembled in integer file N10:0. The header contains the information
for all aspects of the transmission request. Each different node or
instance requires assembling another file. Each file has to be moved in
turn to the output M0 file starting at word 224.
Refer to publication 1747-5.8 - Devicenet scanner module installation
instructions for a detailed description of all coding.
Word M0:1.224
A unique TXID (Transmit Identifier) and Command byte is needed for
this word. The valid command codes are:
TXID cmd/status
Port Size
Service MAC ID
Class
Instance
Attributes
7UDQVDFWLRQ
+HDGHU
ZRUGV
7UDQVDFWLRQ
ZRUGV
%RG\
